Ultimatrue Engineering Industries is a world-class provider of end-to-end electronic and electrical control solutions since 1996. As it's clients' most trusted provider, Ultimatrue Engineering Industries has stimulated synergetic relationships through the unique understanding of the dynamics of its clientele and it's affiliated markets.

#LiftingExpectations



Simplex Elevator Control Boards

XC-8: Up to 8 stops / 12V AC.

XC-8XP: Up to 8 stops expandable to 16 by extension board / 12V AC.

XC-12: Up to 12 stops / 12V AC.

XC-12XP: Up to 12 Stops expandable to 28 by extension board / 12V AC.

XC-16: Up to 16 Stops / 12V AC.

XC-28: Up to 28 Stops / 12V AC.

XCHV-8XP: Up to 8 Stops expandable to 16 by extension board / 24V AC.

Gearless Elevator Control Boards

XC8-GL/2S: Up to 8 stops / Two-speed / Gearless motor type / 12V AC.

XC8-GL/3S: Up to 8 stops / Three-speed / Gearless motor type / 12V AC.

XC-16GL/2S: Up to 16 stops / Two-speed / Gearless motor type / 12V AC.

XC-16GL/3S: Up to 16 stops / Three-speed / Gearless motor type / 12V AC.

Selective Collective Elevator Control Boards

XC-8 SC: Up to 8 stops / 12V AC.

XC-8HV SC: Up to 8 stops / 24V AC.

XC-8GL2S/SC: Up to 8 stops / Two-speed / Gearless motor type / 12V AC.

XC-8GL3S/SC: Up to 8 stops / Three-speed / Gearless motor type / 12V AC.

XC-16GL2S/SC : Up to 16 stops / Two-speed / Gearless motor type / 12V AC.

XC-16GL3S/SC : Up to 16 stops / Three-speed / Gearless motor type / 12V AC.



Duplex Elevators Control Groups

DUP-8: Up to 8 stops

DUP-16: Up to 16 stops

DUP-8GL/2S: Up to 8 stops / Two-speed / Gearless motor type.

DUP-8GL/3S: Up to 8 stops/ Three-speed / Gearless motor type.

DUP-16GL/2S: Up to 16 stops/ Two-speed / Gearless motor type.

DUP-16GL/3S: Up to 16 stops/ Three-speed / Gearless motor type.

Elevators ARD- U-RSKU Series

A wide range of ARDs that support traction and hydraulic Elevators are offered in various models to fit with all elevator's project specifications, door types, and all types of DC, up to 30 hp. Providing the elevator, with smooth and stable rescue operations.

Main Features

- Compatible with En81-20, En81-50.

- Compact mechanical design for space-saving.

- Designed to be installed as a standalone system that integrates easily with the elevator main controller.

-Supports manual (operated by retiring cam), automatic, and semiautomatic doors.

-Supports single-speed, two-speed induction motors with direct or indirect roping.

- The safety of the maintenance technician is endorsed by preventing car movement when power is off during the maintenance process.

- Easy Installation Process that doesn't require any external bridges, which limits breakdowns.

- All Circuits are fused for extra protection such as battery supply, step-up transformer, CAM, Brake supply, shaft common supply (CM+S) etc.

- Separate output for lighting the elevator car during the rescue.

- Easy accessed programming menus via LCD that facilitates adjustment of various programmable control parameters such as: wait time, rescue trials, automatic door time, extra time, brake delay, jog time etc.

- Lift operation status display and error reporting with user-friendly LCD interface.

- The device is powered from four maintenance free SLA 12V-7AHr or 12V-12AHr batteries according to standard loads.

- Drive power range up to approximately (16HP induction motors), extra power can be achieved by using larger capacity batteries.

- Disabling the main panel in case of any Phase failure for achieving maximum safety till the end of the rescue regime.

-Moving the car in the direction of the lower ampere (easiest load) which increases battery lifetime.

- Monitoring the complete safety circuits guarantees outstanding safety and protection.

- Maximum utilization of batteries by distributing loads.

-Availability of battery disconnect switch for turning off the device operation (disabling the device to save battery charge) after the rescue regime ends.



UP-MR Elevator Control Panels

UP-2S: Up to 8 stops / Two-speed / Panel.

UP-2SR: Up to 8 stops / Two-speed / Panel + ARD.

UP-VS: Up to 12 stops / Two-speed / Inverter panel.

UP-VSR: Up to 12 stops / Two-speed / Inverter panel + ARD.



The UP-Compact Elevator Control Panels share the following specifications:



  • Compatible with EN 81-20, EN 81-50, and IEC standards.
  • Easy activation and installation.
  • Smart compact designs.
  • Quality components.
  • Provide an external inspection box.

UP-MRL Elevator Control Panels

UP-MRL Elevator Control Panels

  • Compatible with EN 81-20, EN 81-50, and IEC standards.
  • Easy activation and installation.
  • Smart compact designs.
  • Quality components.
  • Operate up to sixteen stops.
  • Support all motor types: One-speed, two-speed, and hydraulic.
  • Support all door types: Manual, semi-automatic, wait-open automatic, and wait-close automatic.
  • Support all types of brand indicators: XDP-2W & XD-2W, XD-B, and XD-S.
  • Support various dimensions.
  • Support various call collection systems: Down collective, simple collective, and A.P.B. (single-call).
  • Provides numbered wires for easy debugging.
  • Provides 100% quality assured products with the latest electrical testing equipment.
  • Provides user-friendly operations.

Add-On Elevator Control Boards

XE-1: Elevator Extension Board

XPH-380: Phase Sequence Correction Board/ 380V AC

XPH-220: Phase Sequence Correction Board/ 220V AC

XB: Bridge board.

Elevators Indicators

XD-2WP & XD-2W: Programmable indicator with a programming unit.

XD-B: Binary indicator.

XD-S: Serial Indicator.



Elevator Access Control Systems

U-AXS: Elevator Access control.

D-AXS-8: Elevator Destination Control (up to 8 stops)

D-AXS-16 : Elevator Destination Control (up to 16 stops)

D-AXS-24 : Elevator Destination Control ( up to 24 stops)



The Access Control Systems share the following specifications:



  • Easy activation and installation.
  • Quality components.
  • Powerful encryption.
  • Support an unlimited number of users.
  • Provide maximum administrative functionalities.
  • Stand-alone device.
  • Built-in RFID technology.
  • ISO 14443A Mifare (13.56 MHz) proximity card standard.
